Sliding and Roller Shutter Systems
Roller Shutters

Box Milano

> Unit height can be trimmed down by simply cutting the
bottom of the front rails to the required height
> Dimensions listed are outside cabinet dimensions;
unit is designed for 19 mm (3/4") panels
> Slats are made of solid, roll formed aluminum
> Guide track adds 19 mm (3/4") to cabinet depth
> Slat height: 25 mm (1")
> Material: Aluminum

Note
Special sizes of the Box Milano can be special ordered for a minimum
of 5 kits (allow 4–6 weeks for production time)

→ Standard Slats

Min. 300 > Finish: brushed
(11 13/16")

Width 610 (24") 1524 (60")
Height
Height
(1 31/32") 457 (18") 443.17.290 443.17.295
50 533 (21") 443.17.314 443.17.319
Height 610 (24") 443.17.296 443.17.301
134 762 (30") 443.17.302 443.17.307
(5 9/32") 914 (36") 443.17.308 443.17.313
7
> Finish: stainless steel finish
19
(3/4")
610 (24") 1524 (60")
Sliding and Roller Shutter Systems
19 Width Width Height Height
(3/4")
457 (18") 443.17.090 443.17.095
533 (21") 443.17.096 443.17.101
610 (24") 443.17.102 443.17.107
762 (30") 443.17.108 443.17.113
914 (36") 443.17.114 443.17.119

> Finish: matt aluminum

610 (24") 1524 (60")
Width Height Height
610 (24") – 443.17.321
762 (30") – 443.17.322
914 (36") 443.17.324 443.17.323

→ Finish Sample Chain Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Item No.
