Sliding and Roller Shutter Systems
Pivoting Pocket Doors

HAWA Folding Concepta 25

→ Accessories - Door Centering Components

> The door centering components are utilized to magnetically center
folding doors that are installed into cabinets mounted into a
wall recess or into a cabinet designed without a bottom panel
> Magnetic
> Material: Aluminum, clear anodized

Item No.
408.30.229
Door centering position: 2-door and 4-door
Supplied With
Drilling jig

→ Strengthening Profile
Strengthening profile > The strengthening profile reinforces the cabinet top panel for a
with connecting plate 3-door or 4-door folding application if supporting center panels
are not desired
> Opening width: max. 2.8 m (110 1/4")
> Material: Aluminum, clear anodized

Connecting plate Description Length Item No.
2.6 m
Strengthening profile with connecting plate 408.30.970
100 (3 15/16") (102 3/8") 7
Connecting plate – 408.30.400
Note
65
40
(2 9/16") The strengthening profile is available cut-to-size upon request, if this
(1 9/16")
option is chosen the connecting plate has to be ordered separately.
Sliding and Roller Shutter Systems
55
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
M6 110 (4 5/16") 110 (4 5/16")
100 (3 15/16") 110 (4 5/16") (2 5/32")
Profile, pre-assembled Profile, fitted from below Jobsite solution
55 55
65 (2 5/32") (2 5/32")
(2 9/16") 40
(1 9/16")
M6 20 20
19 - 26
Profile, pre-assembled Profile, fitted from below Jobsite solution (25/32") Plan view for a 3-door application (25/32") Plan view for a 4-door application (3/4" - 1 1/32")
55
110 (4 5/16") (2 5/32") 110 (4 5/16") 110 (4 5/16")
55 55
(2 5/32") (2 5/32")

20 20 19 - 26
(25/32") Plan view for a 3-door application (25/32") Plan view for a 4-door application (3/4" - 1 1/32")

www.hafele.com/us FC 7.135
