Hinges and Stays
Lid and Flap Stays

Häfele Maxi Accessories

→ Mounting Bracket for Cabinet → Mounting Bracket for Wood or Aluminum Frame Door

VARIANTA Flat Head
5 #6
2 2
(1/16") (1/16")
6.5
(1/4") 373.66.036/.681 373.69.905
6.5
(1/4") 32.5
41 (1 1/4") VARIANTA
(1 5/8") 5
373.69.908/.912 373.69.909
32 21 27
32 21 (1 1/4") (13/16") (1 1/16")
(1 1/4") (13/16") 45 19.5 12.5
45 (1 3/4") (3/4") (1/2") 20 17.5
(1 3/4") (13/16") (11/16") Ø5
32 Ø6.3 (3/16")
> Material: Steel; Finish: nickel-plated (1 1/4") (1/4") 17
16.6 (11/16")
(5/8") 15
For edge distance (cabinet) Item No. 45 (9/16")
28 (1 1/8") 373.69.907 (1 3/4")
37 (1 7/16") 373.69.906 For doors made of wood or For doors with aluminum
with aluminum frame, from frame 20 mm (13/16")
frame width 45 mm (1 3/4")
→ Soft Closing Mechanism
> Screw mount
> Option of slide-on clip for easy mounting
> From frame width: 45 mm (1 3/4")
> Material: Steel; Finish: nickel-plated

Installation Item No.
Wood screws 373.66.681
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Euro screws 373.66.036
With slide-on clip, for euro screws 373.69.908
With slide-on clip, for wood screws 373.69.912
> For edge distances 28 and 37 mm (1 1/8" and 1 7/16")
> Adjustable dampening distance
> Material: Zinc Alloy → Mounting Bracket for Aluminum Frame Door
9
Finish Item No. > From frame width: 20 mm (13/16")
nickel-plated 373.69.799
Note Installation Item No.
The mounting bracket for the cabinet is not required when using the
soft closing mechanism. With slide-on clip (for easy mounting) 373.69.909
Without slide-on clip 373.69.905
→ Hex Key
Note
Use numbers 1–8 for adjusting the Hinges and Stays
holding power.
Use numbers 9–12 to re-adjust door
after a certain time (if necessary).

> SW10
> Material: Plastic

Color Item No.
gray 235.79.301

Flat head screws pages 12.7-12.8, 12.10, 12.13
Varianta screws page 12.16
