P. 797
Drawer Slides
Ball Bearing
Accuride 115RC
Note
→ Track Weight capacity is based on the type and number of ball carriages. Due
to the extensive variety of applications and possible orientations for this
product, we recommend that customers first test this product in the
intended application. This product is not recommended for high-torque
applications.
→ Carriages
12
(1/2")
M5 x .031
(8 (5/16") x 2)
40
(1 9/16")
10
(3/8")
> Material: Aluminum 6000 series
Length Item No. Material Item No.
1.2 m (47") 421.59.100 Stainless Steel 421.59.801
2.4 m (94") 421.59.101
Polymer 421.59.805
→ End Stop
→ Easy Close Kit, optional
> Material: Aluminum
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
8
Item No.
421.59.500
Supplied With
2 Screws (4 1/8")
105
15 (9/16") 23
→ Hardware Kit, optional (15/16") Drawer Slides
5
60 (3/16")
(2 3/8")
45 (1 3/4")
1.6
(1/16") 12 4
(1/2”) 24 (15/16") 53 (3/16")
Ø4.4 x 8.4 x 90° CSK (2 1/16") 24
38 (3/16" x 5/16" x 90°) (15/16")
(1 1/2")
150 17.5
11 (5 15/16") (11/16")
(7/16") 175
(6 7/8")
Item No.
421.59.521
Item No.
421.59.522
www.hafele.com/us FC 8.117
