Drawer Slides
Ball Bearing

Accuride 115RC

> Linear Motion Track System is a unique movement solution
consisting of lightweight aluminum tracks and re-circulating ball
carriages which provide guidance, movement and positioning for
screens, panels, partitions or other components in industrial,
commercial and institutional applications
> Weight capacity: 120 kg (265 lbs.)
> Track available in two lengths: 1.2 m (47") and 2.4 m (94")
> Corrosion-resistant track may be cut down to the desired length
or butted together to extend to any length
> Re-circulating ball carriages in two options:
- Stainless Steel ball bearing carriage provides the greatest
weight capacity
- Polymer ball bearing carriage is grease-free with smooth
and quiet movement
> Tracks have drilling marks for both the fixing holes and end stops

Note
Weight should be evenly distributed across the carriage(s).

→ Flat Mount (carriage up)
Stainless Steel ball carriage
x1 29 kg (65 lbs.)
x2 54 kg (120 lbs.)
x3 70 (155 lbs.)
Polymer ball carriage
x1 18 kg (40 lbs.)
x2 32 kg (70 lbs.)
x3 41 kg (90 lbs.)
8 → Side Mount
→ Flat Mount (carriage down)
Stainless Steel ball carriage
Stainless Steel ball carriage x1 50 kg (110 lbs.)
Drawer Slides x2 70 kg (155 lbs.) x3 170 (265 lbs.)
41 kg (90 lbs.)
x1
90 kg (200 lbs.)
x2
90 kg (200 lbs.)
x3
Polymer ball carriage
Polymer ball carriage
x1
29 kg (65 lbs.)
x1
23 kg (50 lbs.)
54 kg (120 lbs.)
x2
41 kg (90 lbs.)
x2
72 kg (160 lbs.)
x3
22 x3 54 kg (120 lbs.)
(7/8")
1 M5 Side view Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
4 10 (1/32")
5 (5/32") (3/8") x 90º 5
(3/16") End stops: drill 4.2 (3/16") holes on lines, fully countersunk. (3/16")
15
(9/16")
Bottom view
12 Lengths: 1.2 m (47") & 2.4 m (94")
(1/2") 4 10
50 – 75 (5/32") (3/8") x 90º
(2") (3") Fixing: drill 4.2 (3/16") holes on center line, fully countersunk.
40 (1 9/16")
100 – 200 Carriage Top view
10 (4") (8") 60
111

(3/8") (4 3/8") (2 3/8")
