Drawer Slides
Double-Wall Drawer System

Häfele Matrix Box P50

→ Front Panel Stabilizing Plate

22 (7/8")
Ø4 25 (1") > For stabilizing aluminum panels and panel profiles, and preventing
(3/16") the front panel from bending when pulling out the drawer
6 > Material: Plastic
(1/4")
Ø7.5
(5/16") Color Item No.
white 553.61.780

→ Clip Set for Internal Drawer

50
(1 15/16") > For internal drawer
> For automatic opening of the internal drawer when front panel is
pulled out
> Material: Plastic
105 (4 1/8") 40 (1 9/16") 124 (4 7/8") 112 (4 7/16") Color Item No.

dark gray (matches metallic anthracite)
559.91.992
8 60 gray 559.91.991
(2 3/8")
→ Spacers
Drawer Slides (1 7/16") > Can be used as blocking in face frame applications
37
> Required for internal drawers behind a hinged door
> Material: Plastic

white
553.62.700
25 Color Item No.
(1") Note
Order separately, not included in the set.
2 pcs. required for each slide. Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

FC 8.12 www.hafele.com/us
2/22
