Drawer Slides
Double-Wall Drawer System

Häfele Matrix Box P50

→ Drawer Slides and Side Profiles

> Heavy duty weight rating: 50 or 70 kg (110 or 154 bs.)
> Rack and pinion provides controlled and gentle movement
> Full extension slides allow for maximum access to drawer
> 16 mm (5/8") material is required for the drawer bottom and back
> Profile height: 92 mm (3 5/8")
> Material: Profiles: Steel, powder-coated; Slides: Steel;
Finish: zinc-plated; Cover Caps: Plastic

→ Full Extension with Soft Close

white metallic anthracite champagne
Length 50 kg (110 lbs.) 70 kg (154 lbs.) 50 kg (110 lbs.) 70 kg (154 lbs.) 50 kg (110 lbs.) 70 kg (154 lbs.)
270 (10 5/8") 551.54.720 - 551.54.320 - 551.54.820 -
300 (11 13/16") 551.54.721 - 551.54.321 - 551.54.821 -
8 350 (13 3/4") 551.54.722 - 551.54.322 - 551.54.822 -
400 (15 3/4") 551.54.723 - 551.54.323 - 551.54.823 -
450 (17 11/16") 551.54.724 - 551.54.324 - 551.54.824 -
500 (19 11/16") 551.54.725 - 551.54.746 551.54.325 - 551.54.346 551.54.825 - 551.54.846
Drawer Slides Supplied With Left/right drawer slide, Left/right cabinet profile, 2 Cover caps, Pre-attached back brackets - -
551.54.726
551.54.326
551.54.826
550 (21 5/8")
551.54.827
551.54.327
551.54.347
551.54.747
551.54.727
600 (23 5/8")
650 (25 9/16")
551.54.348
551.54.748
551.54.728
551.54.328
551.54.828
Note Order drawer front fixing brackets separately.
→ Full Extension Push-to-Open with Soft Close
> With integrated soft closing and self-closing mechanisms Length white metallic Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Weight capacity: 50 kg (110 lbs.) anthracite
> Drawer side height: 92 mm (3 5/8") for cabinet width up to 450 (17 11/16") 513.30.734 513.30.334
1200 mm (47 1/4")
500 (19 11/16") 513.30.735 513.30.335
550 (21 5/8") 513.30.736 513.30.336
Supplied With
Left/right drawer sides with rear panel fitting
Left/right cabinet runners
2 Cover caps with Häfele logo
Push-to-open element (553.50.995)
Synchronization rod (551.90.161)
Varianta screws page 12.16
FC 8.8 www.hafele.com/us
