Sliding and Roller Shutter Systems
Lateral Swing Fittings

Swingfront FB 20

> Door weight: max. 20 kg (44 lbs.)
> Inside clearance width of cabinet: min. 398 or 475 mm
(15 21/32" or 18 11/16")
> Inside clearance height of cabinet: max. 2576 mm (8' 5 7/16")
> Adjustment options: ±4 mm (5/32") vertical, ±2 mm (3/32")
horizontal, ±2 mm (3/32") on the incline
> Door wing swings to the front and side during opening
> Use in straight cabinets or in corner solutions
> With integrated soft closing mechanism
> Material: Zinc Alloy, powder-coated; Finish: silver colored

→ Application

A 64
(2 17/32")
273 (348)
(10 3/4" (13 11/16") + A 20.5 +B
(13/16")
7 395 (470)
(15 9/16" (18 1/2")
C
154 (196) D
Sliding and Roller Shutter Systems
257 (332) (6 1/16" (7 23/32")
(10 1/8" (13 1/16")
455 (583) 60
(17 29/32" (22 15/16") (2 3/8")
H E
Single door, A Internal cabinet width L
Dimensions without brackets = internal cabinet width min. 398 mm
Dimensions in brackets = internal cabinet width min. 475 mm
395 (470)
(15 9/16" (18 1/2")

154 (196)
332 (257) (6 1/16" (7 23/32")
20.5 +B
(13 1/16" (10 1/8") (13/16")
395 (470) (15 9/16" (18 1/2") C Door opening mechanism, D Connecting bar
E = Connecting bar length = H – 76 mm (3") = H – 84 mm (3 5/16")
415 (550) when using fixing set
(16 11/32" (21 21/32") L = Internal cabinet width, H = Internal cabinet height Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

→ Corner Solution with Double Doors → Drilling Pattern

A Ø8 x 13
(5/16" x 1/2")
B 32
Ø8 x 13 18 (1 1/4")
(5/16" x 1/2") (11/16")
≤172 14
(6 25/32") (9/16")
36 (1 13/32")
12 (15/32")
A = Lateral door overlay
B = Top and bottom door overlay
Dimensions without brackets = internal cabinet width min. 398 mm (15 21/32")
Dimensions in brackets = internal cabinet width min. 475 mm (18 11/16")
FC 7.106 www.hafele.com/us
