Sliding and Roller Shutter Systems
Vertical Sliding Door Systems

Finetta F-Line 32 23A

Side panel thickness 19 mm (3/4")
Cabinet height H Door height H1 H2 Door width (DW)
B1 B2
900 (35 7/16") – –
1200 (47 1/4")
480 (18/78") 477 (18 3/4") 104.5 (4 1/8")
1800 (70 7/8") 733.5 (28 7/8") 817.5 (32 3/16")
2400 (94 1/2") 1033.5 (40 11/16") 1117.5 (44")
900 (35 7/16") – –
1200 (47 1/4")
600 (23 5/8") 597 (23 1/2") 224.5 (8 13/16")
1800 (70 7/8") 733.5 (28 7/8") 817.5 (32 3/16")
2400 (94 1/2") 1033.5 (40 11/16") 1117.5 (44")
*These dimensions are only listed in milimeters.
Cabinet height H A B C Door width (DW) D
– 900 (35 7/16") 863 (34")
– 1200 (47 1/4") 1163 (45 13/16")
480 (18 7/8") 80 (3 5/32") 160 (6 5/16")
438 (17 1/4") 1800 (70 7/8") 1763 (69 7/16")
438 (17 1/4") 2400 (94 1/2") 2363 (93 1/16")
– 900 (35 7/16") 863 (34")
– 1200 (47 1/4") 1163 (45 13/16")
600 (23 5/8") 76 (3") 224 (8 13/16")
558 (21 15/16") 1800 (70 7/8") 1763 (69 7/16")
558 (21 15/16") 2400 (94 1/2") 2363 (93 1/16")
Installation on cabinet
73
2 (2 7/8”) 7
(3/32”)
X
56
42 36 (2 7/32”)
±2 (1 21/32”) (1 13/32”)
(3/32”)
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
16
(5/8”)
X
Adjustment of the closed door Open door

Cabinet Door width
height H (DW) Door weight Item No. Sliding and Roller Shutter Systems
900 (35 7/16") 6–8 kg (13.2 –17.6 lbs.) 403.25.040
480 1200 (47 1/4") 7–9 kg (15.4–19.8 lbs.) 403.25.050
(18 7/8") 1800 (70 7/8") 10–12 kg (22–26.4 lbs.) 403.25.060
2400 (94 1/2") 15–17 kg(33–37.4 lbs.) 403.25.070
900 (35 7/16") 6–8 kg (13.2 –17.6 lbs.) 403.25.041
600 1200 (47 1/4") 10–12 kg (22–26.4 lbs.) 403.25.051
(23 5/8") 1800 (70 7/8") 15–17 kg(33–37.4 lbs.) 403.25.061
2400 (94 1/2") 21–23 (46.2–50.7 lbs.) 403.25.071
*The 480 mm (18 7/8") version is a special order and will have
a longer lead time.
Supplied With
Supporting aluminium profile
Pair of extending sliding rails
Sliding rail for center intermediate panel (only for door widths
1800 mm (70 7/8") and 2400 (94 1/2")
Mounting hardware

www.hafele.com/us FC 7.105
