Connectors and Shelf Supports
Furniture Connectors
Dowel Connectors
→ Spreading Dowel
Length > With M6 internal thread for press-fit installation
> Extremely high pull-out strength
for Ø8 M6
hole > Drill depth should be dowel length plus 2 mm
> Material: Brass, bright
Version Length Item No.
W/O nylon ball 9.5 039.00.267
W/nylon ball 12 039.00.061
→ Spreading Dowel
> With M4 internal thread
M4 Ø5 > Material: Brass, bright
8
Item No.
051.45.004
→ Spreading Dowel
9.5
> Without collar
> Material: Nylon
Ø5
Color Item No.
natural 042.98.033
→ Spreading Dowel
Connectors and Shelf Supports
for Ø10 mm hole > With M6 internal thread
> Material: Nylon
13
12 pieces Color Item No.
12 molded together natural 039.35.064
→ Spreading Sleeve
for Ø5
holes > Without collar
> Material: Nylon
20 piece
12 strip
Color Item No.
