Connectors and Shelf Supports
Furniture Connectors

Multi-Purpose Connectors

→ T-Nuts
Length > Pronged
> Material: Steel, unfinished
Sleeve Ø Outer Ø
Internal
Rim thread Outer Ø Sleeve Ø Rim Length Item No.
M4 15 5.5 1 7.5 031.00.249
M6 19 7.5 1.3 8 031.00.267
M8 22.5 10 1.5 9.5 031.00.285
M10 26 11.5 2 11 031.00.301

→ Screw-in Sockets

Length
> Screwdriver slot
> Internal thread M4
Minor Ø Outer Ø > Material: Steel, unfinished

Outer Ø Minor Ø Length Item No.
8 5.5 8 030.00.100
Supplied With
1000 pcs.

> Internal thread M6

Outer Ø Minor Ø Length Item No.
10 7 12 030.00.351
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Internal Outer Ø Minor Ø Length Item No.
thread
M8 14 11.5 15 030.00.404
M10 18.5 15 15 030.00.502
Supplied With
100 pcs.

→ Glue-in Sockets Connectors and Shelf Supports

Length
> Glue grooves
Outer Hole > Internal thread M4
Ø Ø > Material: Nylon; Color: natural
Outer Ø Hole Ø Length Item No.
8.5 8 8 039.33.140
8.5 8 10 039.33.042

> Internal thread M6
11
Outer Ø Hole Ø Length Item No.
8.5 8 11 039.33.462
> Internal thread M6

Outer Ø Hole Ø Length Item No.
11 10 11 039.33.266
Supplied With
5000 pcs.
