Connectors and Shelf Supports
Panel Connectors

Fastmount Panel Mounting System
®
> No visible fittings
> Self-aligning installation
> Perfect alignment and secure mounting
> Remove and refit panels multiple times
> Allows for panel flex and expansion
> Suitable for a variety of materials
> Self-tapping fittings

→ Standard Profile, heavy-duty, male → Complete Tool Kit

Ø20 > For standard profile range
17.3
(13/16") (11/16")
7.5
(5/16") Item No.
2 (1/16")
267.20.028
> Mounts into 10 mm drilled hole
> Pull-out weight capacity per clip: 10 kg+
> Material: Plastic
→ Drill Bit
Color Item No.
black 267.20.313 > Use to drill frame for Fastmount
self-tapping female fitting
> 16.8 mm drilling diameter
→ Standard Profile, male > Material: Carbide-tipped

Ø20 Item No.
(13/16") 17.3
(11/16") 267.20.032
5.5
(3/16")
2 (1/16") → Installation Tool
> Mounts into 10 mm drilled hole
Connectors and Shelf Supports
> Pull-out weight capacity per clip: 5 kg+ > Use to install Fastmount self-tapping
> Material: Plastic male fitting
> Material: Aluminum
Color Item No. Finish Item No.
white 267.20.710
black 267.20.029
→ Standard Profile, female
→ Installation Tool
Ø20 17.8
(13/16") (11/16") > Use to install Fastmount self-tapping
15 female fitting
(9/16") > Material: Aluminum
Ø11 12 14.7
(7/16") (1/2") (9/16")
Finish Item No.
2
(1/16") black 267.20.040 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Mounts into 16.8 mm drilled hole → Standard Profile, female
> Pull-out weight capacity per clip: 5 kg+
> Material: Plastic 1.6
11 Ø25 (1/16")
2.9
Color Item No. (1") (1/8")
white 267.20.711 29
Ø3.5 (1 1/8")
(1/8")
7 (1/4") 4.9
11 (3/16") 9.7
(7/16") (3/8")

> Use to mark drilling location for Fastmount male fitting
Item No.
267.20.941
