Connectors and Shelf Supports
Panel Connectors

Button-fix Panel Connecting Fittings
™

→ Button → Button Marker Tool

Ø 18

Flat Head VARIANTA
8
#10 5
> To be used in conjunction with Button-fix type 1
™
> To be used in conjunction with any of the Fixes > Quickly and accurately align the Button-fix installation without
™
> Material: Plastic measuring
> The marker will leave indents in the mating panel surface which
can be used as a guide
Color Mounting Item No. > Ø: 18 mm
green countersunk wood screw 262.94.030 > Material: Plastic
orange euro screw 262.94.031
Note Order screws separately. Color Item No.
red 002.84.750
→ Fix Marker Tool
→ Multi Jig

> To be used in conjunction with Button-fix type 2
™
> Quickly and accurately align the Button-fix installation without
™
measuring
> The marker will leave indents in the mating panel surface which
can be used as a guide
Connectors and Shelf Supports
> L x W: 50 x 25 mm
> Material: Plastic
> Designed to help mortise Button-fix Type 1,Type 1 Bonded
™
and Type 1 Flush Fix
Color Item No. > For use with a metric 12 mm cutter and a 30 mm guide brush
red 002.84.751 > Material: Plastic
→ Safety Cord Item No.
002.84.752
Supplied With
Magnetic steel plate – creates an oval mortise for Type 1 and Type 1
Bonded Fixes. Square plates can be oriented vertically or horizontally
in the frame.
Magnetic steel plate – creates an oval mortise for Type 1 Flush Fix.
Square plates can be oriented vertically or horizontally in the frame. Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

11
> To be used in conjunction with Button-fix type 2
™
> An additional button is used to capture the loop on the safety
cord, installed adjacent to the fixing button
> The loop on the safety cord must be manually eased off the
button to remove the panel
> Install 2 safety cords on a vertical panel
> Material: Plastic

Color Item No.
black 262.94.025 Varianta screws page 12.16
Note Button must be ordered separately. Flat head screws pages 12.7-12.8, 12.10, 12.13
