Connectors and Shelf Supports
Panel Connectors

Fastmount Panel Mounting System
®

> No visible fittings
> Self-aligning installation
> Perfect alignment and secure mounting
> Remove and refit panels multiple times
> Allows for panel flex and expansion
> Suitable for a variety of materials
> Self-tapping fittings for thinner materials

→ Low Profile, male → Low Profile, female

6
(1/4") Ø30 6°
Ø11 23
(7/16") Ø24
12
(1/2") 11 15
(7/16") 2
Ø24
(15/16") 11 (7/16") Ø19
6 Ø10 24
(1/4") 2 (1/16") 29
10 19
(3/8")
11
(7/16") > Mounts into 25 mm drilled hole
> Pull-out weight capacity per clip: 5 kg+
> Mounts into 10 mm drilled hole > Material: Plastic
> Pull-out weight capacity per clip: 5 kg+
> Material: Plastic
Color Item No.
white 267.20.721
Color Item No.
white 267.20.718
→ Low Profile, female
→ Installation Tool
Ø30
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Use to install Fastmount self-tapping 23
3°
female fitting
> Material: Aluminum 2 11
Ø24 24
Finish Item No. 29
black 267.20.027 19

> Mounts into 25 mm drilled hole Connectors and Shelf Supports
→ Installation Tool > Pull-out weight capacity per clip: 5 kg+
> Material: Plastic
> Use to install Fastmount self-tapping
male fitting
> Material: Aluminum Color Item No.
white 267.20.719
Finish Item No.
black 267.20.029

→ Installation Tool
11
3.2
1.5 (1/8") 2.9 > Use to mark drilling location for Fastmount male fitting
(1/16") (1/8") Ø28 > Material: Plastic; Center Point: Stainless Steel
7.5 (1 1/8")
(5/16")
9.9 Color Item No.
(3/8") 6.1 Ø3.9
16.6 (1/4") (1/8") red 267.20.943
(5/8")

www.hafele.com/us FC 11.89
