Connectors and Shelf Supports
Connectors
Häfele Rafix System
> Tightening with #2 Pozi drive or flat-blade screwdriver
8
or
10
→ Connecting Bolt
7.5 9
> With M6 thread
> Screws into dowels or sleeves for single-sided assemblies
6.5 M6 Ø7
> Dowels or sleeves can be selected for Ø8 or Ø10 mm holes
> Material: Steel, galvanized
Item No.
263.21.826
The connecting bolt above can be used with the following dowels:
→ Spreading Dowel
Length > With M6 internal thread
> Material: Brass, bright
for Ø8 mm
hole M6
Drilling depth = Length Item No.
2 mm > insert length 9 039.00.267
12 w/nylon ball 039.00.061
Connectors and Shelf Supports
→ Glue-in Dowel
11 > With M6 internal thread
> Material: Nylon
for Ø8 mm M6
hole
Color Item No.
natural 039.33.462
→ Glue-in Dowel
11
> With M6 internal thread
> Material: Nylon
for Ø10 mm M6
hole
Color Item No. Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
natural 039.33.266
→ Spreading Dowel Strip
11
for Ø10 mm hole > With M6 internal thread
> Material: Nylon
13
12 pieces Color Item No.
12 molded together natural 039.35.064
