Locks and Catches
Mains-Operated Furniture Locks

EFL 41 Glass Sliding Door Lock

→ For Sliding Glass Doors

19.5 13 24.2
(3/4") (15/16")
19.5 (1/2")
58.5 (2 5/16") 72 (2 13/16") (3/4") 1
3
(1/8") 20 (1/32")
24 (13/16")
(15/16")
134 (5 1/4")
150 (5 7/8")

Technical data > Electric lock for indoor use: For sliding glass doors in furniture
> Voltage supply 12–24 V DC in load operation, "toggle" mode and office equipment
(permanent open) only permitted with 12 V DC power supply > The lock remains unlocked for 3 seconds via the FT 120/FT 200
> The max. open time in "lock cycle" mode is 15 minutes (standard), the door is locked again after 3 seconds, integrated
> Power consumption 1.75 W with 13 V DC (135 mA) feedback contact "Lock Locked/Unlocked"
> 3.0 W with 17 V DC (175 mA) > Locking unit for sliding into the Häfele Slido Design 25 IF G double
> 6.0 W with 24 V DC (250 mA) bottom running track, connection cable with AMP plug
> Tensile load >200 N > FT 120 furniture terminal: Connection via CC 140 distributor,
FT 200 furniture terminal: Connection via MLA 8 multi-lock adapter
Feedback contact: > For glass thickness: 6 and 8 mm (1/4" and 5/16")
> Operating voltage: max 30 V DC > Sliding door lock: For groove mounting into cabinet base panel
> Operating current: max. 300 mA > Double running track: For screw mounting to cabinet base panel
> Switching capacity: max. 5 W > Runner catch: For installation in Häfele Slido Design 25 IF G
> Sensor resistance 180 mΩ runner housing profile
> Operating mode Currentless closed ("fail safe"), "permanent open" > The EFL 41 sliding glass door lock can only be used in combination
mode not permitted (overheating), except with 12 V DC with the Häfele Slido Design 25 IF G sliding door fitting
> Cable length: 3 m (118") (with AMP plug) > The integrated feedback contact (open door alarm for glass sliding
> Operating temperature 0–50 °C doors, for example) can be used optionally
Keyed alike furniture locks > A macro is required for controlling the feedback contact
> Several EFL 41 sliding glass door locks can be switched parallel (available on request)
(keyed alike) with the FT 120 in combination with the CC 140 > Material: Housing: Plastic; Double running track: Aluminum
distributor and with the FT 200 in combination with the MLA 8
multi-lock adapter
Item No.
Keyed alike/keyed different furniture locks: 237.56.971
> Several EFL 41 glass sliding door locks can be switched parallel
(keyed alike) or individually keyed different) in combination with Supplied With
the MLA 8 multi-lock adapter Locking unit pre-mounted under 150 mm (5 7/8") Häfele Slido Design
> Using the MLA 8 also allows: Parallel operation of keyed alike 25 IF G double running track
and keyed different Runner catch
Combination with other EFL Feedback control
furniture locks with AMP plug Note
(e.g. EFL 1) Only to be used for sliding glass doors. Bottom running track length
(Häfele Slido Design 25 IF sliding door fitting): Internal cabinet
dimensions – 2 x 150 mm (5 7/8") 2 x locking unit) PS power supply
10 Technical Data unit must be used for supplying power.
Voltage supply 12 V DC
Continuous current consumption 184 mA Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Pull 90 kg
Locks Operation mode Currentless closed ("fail locked") or
currentless open ("fail unlocked")
3 m (118") (with AMP plug)
Cable length
Operating temperature –10 to +50 °C

FC 10.100 www.hafele.com/us
