Locks and Catches
Mains-Operated Furniture Locks

EFL 3 and EFL 3C

→ CC 200 Connection cable

> For connecting an EFL 3 or EFL 3C furniture lock to the
MLA 6P/MLA 8 multi-lock adapter or the FT 200 / FT 200 CAP
furniture terminal
> With mini plug and RJ10 plug
> Color: black

Cable length Item No.
0.5 (19 11/16") 237.59.020
1 (39 3/8") 237.59.021
3 (118 1/8") 237.59.022
5 (196 7/8") 237.59.023
10 (393 23/32") 237.59.024
Note
The connection cables are only compatible with the EFL 3 (237.59.000)
and EFL 3C (237.59.001) furniture locks of the current generation
(see page 10.292).

→ EFL 3/EFL 3C DG2 Adapter cable

> For connecting the current version of the EFL 3 (237.59.000)
and EFL 3C (237.59.001) furniture locks with the previous
version of the V2 connection cable (237.56.340–237.56.349).
> With previous mini plug and new mini plug
> Color: black

Cable length Item No.
100 (4") 237.56.335
Note
For replacing EFL 3 (237.56.304) and EFL 3C (237.56.305)
furniture locks of the previous generation in existing systems with
EFL 3 (237.59.000) and EFL 3C (237.59.001) furniture locks of the
current generation, without changing the connection cables.

10 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
