Hinges and Stays
Lid and Flap Stays
Häfele Maxi
> For wood or aluminum framed doors
> All common applications for doors and openings can be achieved
by changing mounting position and combining Maxi with the
appropriate accessories
> Applications include fronts with and without handle and aluminum
frame, automatic opening to the end position, multi-position stop
and easy opening of heavy fronts
> Can be used on one or both sides depending on the size of the
door
> Holding power can be adjusted individually to respective flap
weight
Front adjustment facility
A
B
*Height *Side *Tilt Holding power adjustment
adjustment adjustment adjustment with SW10 Hex key,
D see page 9.124
Note
*Depends on the hinges that are installed.
9 C
Overview of finish designation
