Drawer Slides
Double-Wall Drawer System

Salice Lineabox

→ Drawer Side Height: 178 mm (7") → Drawer Side Height: 237 mm (9 5/16")

9 (3/8") 10 (3/8") 9 (3/8") 10 (3/8")

196 (7 11/16") 255 (7 11/16")

193 (7 5/8") 252 (9 15/16")

12 (1/2") 41 (1 5/8") 12 (1/2")

31.5 38 (1 1/2") 29 (1 1/8") 12 (1/2") 41 (1 5/8") 12 (1/2")
(1 1/4") 38 (1 1/2") 29 (1 1/8")
29 26 31.5
Futura slides (1 1/8") (1") F70 slides (1 1/4")
26
29 (1")
stainless Futura slides (1 1/8") F70 slides
Length white gray steel look
229 (9") 555.83.720 555.83.520 555.83.020 Length white gray stainless
steel look
305 (12") 555.83.721 555.83.521 555.83.021 229 (9") 555.83.730 555.83.530 555.83.030
381 (15") 555.83.722 555.83.522 555.83.022 305 (12") 555.83.731 555.83.531 555.83.031
457 (18") 555.83.723 555.83.523 555.83.023 381 (15") 555.83.732 555.83.532 555.83.032
533 (21") 555.83.724 555.83.524 555.83.024
457 (18") 555.83.733 555.83.533 555.83.033
Note Requires 8 front/back fixing clips. 533 (21") 555.83.734 555.83.534 555.83.034
Supplied With 12 pcs./box - members are non-handed Note Requires 12 front/back fixing clips.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Supplied With 12 pcs./box - members are non-handed 8
→ Front/Back Fixing Clips

Mounting Item No.
Dowel (5 mm) 555.82.313
Screw (2x Ø3.5 mm x 20 mm) (supplied) 555.82.310
Rapid assembly of non-handed sides Drawer Slides
1 2 3 4

Attach external connectors Push to engage external Attach back with snap-in connectors Insert 16 mm (5/8") bottom
with 5 mm (3/16") dowels and internal connectors
or pozi drive wood screws
5

Runner length Unique double notch profile,
front and back, results in a fully
Attach sub-front with finished product and eliminates
the need for "short-edge"
snap-in connectors edgebanding
Futura soft close slides page 8.56
Futura push slides page 8.60
F70 slides pages 8.62A–8.62B

www.hafele.com/us FC 8.41B
11/22
