Drawer Slides
Double-Wall Drawer System

Salice Lineabox

> Metal drawer system with clean, simple lines and minimal wall
thickness to maximize internal space
> For use with Salice Futura and F70 undermount drawer slides
(Soft close or Push), see pages 8.56, 8.60 and 8.62A–8.62B
> Rapid assembly with clip connectors eliminates the need
for machines or templates
> Sides are notched front and back for a completely finished
appearance without the need for “short-edge” edgebanding
> 16 mm (5/8") bottom, back and sub-front material
> Non handed
> Lifetime warranty
> Material: Aluminum

→ Drawer Side Height: 75 mm (3") → Drawer Side Height: 101 mm (4")

9 (3/8") 10 (3/8") 9 (3/8") 10 (3/8")

12 (1/2") 93 (3 11/16") 90 (3 9/16") 38 (1 1/2") 12 (1/2") 12 (1/2") 119 (4 11/16") 116 (4 9/16") 38 (1 1/2")

31.5 (1 1/4") 29 (1 1/8") 41 (1 5/8") 29 (1 1/8") 41 (1 5/8") 12 (1/2")

26
Futura slides (1") F70 slides 31.5 (1 1/4") 29 (1 1/8") 26 (1") 29 (1 1/8")
Futura slides F70 slides
8 stainless stainless
Length white gray Length white gray
steel look steel look
229 (9") 555.83.700 555.83.500 555.83.000 229 (9") 555.83.710 555.83.510 555.83.010
305 (12") 555.83.701 555.83.501 555.83.001 305 (12") 555.83.711 555.83.511 555.83.011
Drawer Slides Note 555.83.703 555.83.503 555.83.003 Note 555.83.713 555.83.513 555.83.013
555.83.012
555.83.002
555.83.502
381 (15")
555.83.712
381 (15")
555.83.512
555.83.702
457 (18")
457 (18")
555.83.514
555.83.014
533 (21")
555.83.714
555.83.504
555.83.004
555.83.704
533 (21")
Requires 4 front/back fixing clips.
Requires 4 front/back fixing clips.
Supplied With
Supplied With
12 pcs./box - members are non-handed
Cutting the length and width 12 pcs./box - members are non-handed
OUTSIDE BACK
for the bottom
17 mm (11/16") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
11 mm (7/16")
(X - 22) ± 1 mm (1/16") = Futura DRILL BIT
(X - 23) ± 1 mm (1/16") = F70
Futura:
Ø7 x 10 mm (9/32")
Bottom length =
F70:
Runner length - 32 mm (1 1/4")
Ø6 x 10 mm (1/4")
Futura soft close slides page 8.56
Futura push slides page 8.60
F70 slides pages 8.62A–8.62B
