Drawer Slides
Double-Wall Drawer System
Grass Nova Pro Scala
→ Marking Jig Set → Punch-In Tool
> For positioning and installing the front brackets
> For exact marking of the drill holes for the front brackets
Version Item No.
Version Item No. H63 558.18.080
H63 558.18.072 H90/H186 001.35.100
H90 558.18.071
H186/H250 558.18.075
→ Insertion Die
> For positioning and installing the front clip
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
8
Item No.
> For dowelled front brackets
> Works with Grass Pro 1 and Ecopress machines 558.18.090
Drawer Slides
Item No.
001.97.272
Note
Grass machine program available, please inquire for details.
> For positioning and installing the front-bottom connector
Item No.
558.18.092
