Sliding and Roller Shutter Systems
Sliding Glass Door Fittings
→ HAWA Regal A 25 GR VF Set
Supplied With Item No.
2 running gears, single roller
2 guides
For 1 aluminum frame sliding door Frame mounting set (4 angles) 405.55.111
2 stoppers, 1 left hand/1 right hand
2 guide buffers
Note
The complete set is always delivered without track, lower guide channel, glass profiles and accessories. Please order separately.
→ Tracks and Accessories
Description Material Finish Length Item No.
Pan Head Upper track, with screw holes Aluminum anodized 2.5 m (8' 2 7/16") 405.56.002
#6
Lower guide channel, with screw holes, for screw
mounting in cabinet bottom with minimum Aluminum mill 2.5 m (8' 2 7/16") 405.30.026
19 mm (3/4") wood thickness
2.5 m (8' 2 7/16") 405.58.002
Door frame profile Aluminum anodized,
silver
3.5 m (11' 5 11/16") 405.58.003
Glass gasket Plastic gray 2.5 m (8' 2 7/16") 401.65.526
7
Intermediate door stop, optional Plastic gray – 405.33.030 Sliding and Roller Shutter Systems
