Connectors and Shelf Supports
Connectors

Lamello Cabineo Cabinet Connector

> Corner and center panel connections, for use with CNC;
edge drillings are not required
> Pre-mounted for quick and easy installation; additional dowels
and screws are not required
> High clamping force ensures a solid, positive-fit connection
> Separable
> Easily transported, flat pack delivery
> For use with or without cover caps

→ Cabineo → Cover Caps
0.8 > Material: Plastic
33.8 (1/32")
(1 5/16")
10
(3/8") Color Item No.
signal white RAL 9003 267.91.267
brown beige RAL 1011 267.91.264
16.5
(5/8") window gray RAL 7040 267.91.265
papyrus white RAL 9018 267.91.268
mouse gray RAL 7005 267.91.263
black RAL 9005 267.91.262
5 dark steel 267.91.257
Ø5 (3/16")
(3/16") 11 16 nickel 267.91.258
(7/16") (5/8")
silver 267.91.259
X 26 (1") Supplied With 100 pcs.
14.8
(9/16")
3.6 15 Note The colors indicated are similar to RAL
(1/8") (9/16") colors and are as close as possible to the actual
standard colors, but may vary slightly in
production.
Connectors and Shelf Supports
> Press-fits into base panel and screw mounts into side panel → Cabineo Starter Kit
with Ø5 mm drill hole
> For wood thickness: Cabineo 8: from 12 mm, center panel
from 16 mm; Cabineo 12: from 16 mm
> Material: Plastic, fiberglass reinforced; Screw: Steel

Version Dim. X Color Item No. Packing
267.91.251 500 pcs.
white
Cabineo 8 8 267.91.271 2000 pcs.
500 pcs.
267.91.253
black
267.91.273 2000 pcs.
267.91.252 500 pcs. Item No.
white 267.91.272 2000 pcs. signal white RAL 9003 267.91.200
Cabineo 12 12
black 267.91.254 500 pcs. Supplied With 40 Cabineo 8, 40 Cabineo 12, 40 Cover caps,
267.91.274 2000 pcs. 120 mm SW4 hex bit with ball head Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
→ Driver Bits → Screwdriver with 1/4" Bit Holder
11

> 1/4" drive with 4 mm ball tipped hex driver

Length Item No. Bulk
120 001.26.605 - > For screw fixing the Lamello Cabineo connector
80 006.40.002 006.40.003
Bulk Supplied With Item No.
100 pcs./pkg. 001.26.604
