Connectors and Shelf Supports
Connectors
261.16.710
Surface Mounted Connectors
13
→ Surface Connector → Surface Connector
34 7
Flat Head
#6
29.5
23 15.5
15
Shown in black
47 32
32
Flat Head 15
15 #6
7.5
19.5 33
10 13
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Screw mounted
> Material: Plastic
> Two rectangular, screw mounted elements (male and female,
with taper effect), provide a secure interlocking grip, locked
Color Item No. together by a clamping plate
white 261.16.710 > Material: Clamping plates: Steel
Mounting elements: Plastic
→ Uno I RTA Connector
Color Item No. Connectors and Shelf Supports
white 262.67.701
Supplied With
2 Elements
for drill hole Ø10 mm
for drill hole Ø5 mm
Side panel
> Screw mounted in Ø5 mm hole to side panel and press 11
fitting into Ø10 mm hole in side panel
> Material: Plastic
Color Item No.
white 262.41.707
brown 262.41.109 Clamping plate
Flat head screws pages 12.7-12.8, 12.10, 12.13
