Locks and Catches
Pressure Catches

Magnetic Latches

→ Push Latch
45
(1 3/4") > With extra long throws
> Extremely reliable
12 > Longer throw (push) than other catches
(1/2")
> For overlay door, give 3 mm (1/8") gap between door and cabinet
23 Strike frame for pushing space
(7/8") > Magnetic pull: 1.4 kg (3 lbs.)
1.4
(1/16") > Material: Catch: ABS; Strike: Metal; Finish: yellow galvanized
44.5 (1 3/4")
6.5 (1/4") 38 (1 1/2") Color Item No.
6 (1/4") 13 white 245.61.730
(1/2")
brown 245.61.330
15
(9/16") Supplied With
28 Screws
(1 1/8")
15
20
(9/16") (13/16") 36
(1 7/16")
7
(1/4")
15
5 (9/16") 9.5 Catch
(3/16") (3/8")

→ Push Latch

> With extra long throw of 40 mm (1 19/32")
> Longer throw (push) than regular catches
> Works with thick doors
> Allows greater clearance for opening the door
> Magnetic pull: 2.4 kg (5.3 lbs.)
> Material: Catch: ABS; Strike: Metal; Finish: yellow galvanized

Color Item No.
white 245.61.740
brown 245.61.140
Inset Application black 245.61.340
Supplied With
Screws
10 Ø4.2 x Ø8.2
Door
(3/16" x 11/32") 3.5 (5/32") Ø4.2, Ø8 4.5 x 8.5 (3/16" x 11/32")
3 (1/8") (Ø3/16", Ø5/16") 8 x 12.5 (5/16" x 1/2")
Overlay Application Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
12 (15/32") 6 (1/4")
Locks Gap = 3 mm (15/16") 18 (23/32") (29/32") (1 11/32") (1 13/16")
24
23
46
34
(1/8")

34
(1 11/32")
Door 46
(1 13/16")
4 (5/32") 5.5 (7/32") 30 (1 3/16")
5 (7/32") 40 (1 19/32") 10 (3/8")
70 (2 3/4")
115.5 (4 9/16")
7.8 (5/16")
17 (11/16")
6 (1/4") 7.2 (9/32")
