Locks and Catches
Magnetic Catches

Catches

> Hermetically sealed for corrosion resistance
> No metal to metal contact
> Strong magnetic force

→ Catch → Catch

35 (1 3/8") 35 (1 3/8") 53
10 12 15 (2 1/8")
14
(3/8") (1/2") (5/8") 9 (3/8") (9/16")
16
(5/8") 25 Ø4.2
25 (1") (1") (3/16")
1.2
1 2.2 (1/16")
(1/16") (1/8") 7 (5/16") 18 (11/16") 19 (3/4")
42
> Ultra thin catch ideal for tight spaces Pan Head (1 11/16") 7.5
63
> Max. temperature: 80° C (176° F) #6 (2 1/2") (5/16")
> To avoid damage, counter plate should not hit magnet
> Screw heads should not protrude above the base plate
> Holding power: approximately 2.7 kg (5.9 lbs.) > Holding power: approximately 5 kg (11 lbs.)
> Material: Magnet: Neodymium > Material: Catch: Polyacetal; Magnet: Neodymium
Base/Yoke Item No. Color Item No.
Steel, nickel-plated 246.53.650 light gray 246.53.522
Stainless Steel/epoxy 246.53.020 Note
Supplied With Strike plate, 4 pcs. wood screws Optional counter plate – see below.
→ Catch → Catch

41 (1 5/8") 12 2 3 12 12 *
15.5 Flat Head
(5/8")
o
10.5 16.5 #4 - - C
(3/8") (5/8") 40 30 45
28 (1 1/8") 37
2.6
(1/8")
Strike
Flat Head Pan Head Catch
> Ultra thin catch with extra strong magnetic force #4 #4
> Max. temperature: 80° C (176° F)
> To avoid damage, counter plate should not hit magnet > Screw mounted
> Screw heads should not protrude above the base plate > Metal case provides heat-resistance to 300° C.
> Material: Magnet: Neodymium > Holding power: approximately 5 kg (11 lbs.)
> Material: Catch: Aluminum; Strike: Steel
10 Base/Yoke Holding Power Item No. Item No.
Steel, nickel-plated 4 kg (8.8 lbs.) 246.53.640
Steel, black 4 kg (8.8 lbs.) 246.53.300 246.92.000 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Stainless Steel 4 kg (8.8 lbs.) 246.53.000 Note
Holding power is diminished by 1% per 5° C (+) increase in
Locks Note Optional counter plate – see below. temperature. Cooling restores the magnet’s holding power to its
8 kg (17.6 lbs.)
Steel, nickel-plated
246.53.600
original level. No strike is necessary with steel doors or lids.
→ Counter Plate, optional
49 (2") 4.5 > Material: 316 Stainless Steel, unfinished
7.5 40 (1 9/16") (3/16") Flat Head
(5/16") 15 #4
(5/8") Item No.
2
(1/16") 246.53.030

Flat head screws pages 12.7–12.8, 12.10, 12.13
Pan head screws pages 12.9–12.10, 12.13
