Locks and Catches
Magnetic Catches

Catches

→ Catch → Counter Plate, optional
Ø9.6 (3/8")
5.6 Flat Head Flat Head
(1/4")
#6 49 (2") 4.5 #4
45 (1 3/4") 8.5 7.5 40 (1 9/16") (3/16")
7.5 30 (21/64") (5/16") 15
(5/16") (1 3/16") (5/8")
17 2
(11/16") (1/16")

> Hermetically sealed for corrosion resistance > Material: 316 Stainless Steel, unfinished
> To avoid damage, counter plate should not hit magnet
> Screw heads should not protrude above base plate
> Holding Power: approx. 3 kg (6.6 lbs.) Item No.
> Material: Catch: Plastic; Magnet: Neodymium 246.53.030

Color Item No.
black 246.53.320
white 246.53.700
Note
Optional counter plate, see right.

→ Magnet

6.5 11 22 22 1.5 > For metal cabinets
> Holding power: approximately 3 kg (6.6 lbs.)
> Material: Catch: Metal; Strike: Steel
M5
Catch Strike Item No.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Flat Head
#4 246.96.008
→ Magnet
7 25 > Screw mounted
> With inside mounting hole
11.5 5.5 > Low-profile magnet
> For metal cabinets
Flat Head
#9 Catch > Inside mounting Ø5 mm diameter
> No strike needed for metal doors
> Holding power: approximately 3.6 kg (7.9 lbs.)
> Material: Steel
10
Finish Item No.
zinc-plated 246.86.025

→ Magnet Locks

23.5 SW 22 19 3.5
> For metal cabinets
> Holding power: approximately 7 kg (15.4 lbs.)
M18 > Material: Catch: Metal; Strike: Steel
3
Catch Strike Item No.
246.95.010
Flat Head
#4

Flat head screws pages 12.7–12.8, 12.10, 12.13
