Locks and Catches
Cabinet Locks

National Locks High Security

Note > Locks on this page meet or exceed ANSI/BHMA Grade 2
The PLUS feature allows you to (Grade 1 available upon request)
remove the cylinder from our pin > Approved by the Woodworkers Institute (formerly WIC)
tumbler box locks while the lock
remains in place. No mounting Note
screws need to be removed. Custom Master keying and General Master key systems available
Simply use a 2 mm (5/64") upon request.
hex wrench from the back to 2000 key changes are possible, special order 5 pin tumblers:
remove the cylinder for re-keying. - Please include a key plan
- Plan on 2–3 weeks to produce
→ C8178 and C8179 Drawer Locks

> 4 pin tumblers include 850 key changes → Keyed Different
> Surface mounted, requires a Ø24 mm (15/16") hole
> Bolt travel 19 mm (3/4")
> Key turn 360º > Material: Brass-plated

4 Finish Cylinder length National No. Item No.
(5/32")
brushed chrome 22 (7/8") C8178-KD-26D 232.14.300
3 19 brushed chrome 35 (1 3/8") C8179-KD-26D 232.14.350
(1/4") (3/4")
satin brass 22 (7/8") C8178-KD-4 232.14.600
31 satin brass 35 (1 3/8") C8179-KD-4 232.14.650
(1 15/64")
Cylinder Supplied With
length 2 Keys, Strike plate, Screws
12
(15/32")
22 → Master Keyed, Keyed Different
(7/8")
> Random key numbers only
23
(15/16") Cylinder length National No. Item No.
22 (7/8") C8178-MKKD-26D 232.14.347
34
(1 21/64") 35 (1 3/8") C8179-MKKD-26D 232.14.397
40
(1 5/8") Supplied With 2 Keys, Strike plate, Screws
Note Order master key and cylinder rosettes separately, below.
→ Master Key → Cylinder Rosettes

> For MKKD locks above
> Material: Brass

10 National No. Item No. (7/8") (5/16")
8
Ø22
D4299
210.02.209
Ø23
→ Keyed Alike Mounting hole Ø29 (59/64") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Ø24 (15/16") (1 9/64")
Locks > Bolt travel 3/4" > Material: Brass
Cylinder Cylinder Finish National No. Item No.
Finish Keying National No. length National No. length
#’s 22 mm (7/8") 35 mm (1 3/8") brushed chrome C2017-26D 232.14.000
101 C8178-101-26D 232.14.301 C8179-101-26D 232.14.351 satin brass C2017-4 232.14.001
brushed 103 C8178-103-26D 232.14.302 C8179-103-26D 232.14.352
chrome 107 C8178-107-26D 232.14.303 C8179-107-26D 232.14.353
915 C8178-915-26D 232.14.304 C8179-915-26D 232.14.354
satin 107 C8178-107-4 232.14.603 C8179-107-4 232.14.653
brass 915 C8178-915-4 232.14.604 – –
Supplied With
2 Keys, Strike plate, Screws Keyed alike replacement keys page 10.39
