Locks and Catches
Cabinet Locks

National Locks High Security

Note > Locks on this page meet or exceed ANSI/BHMA Grade 2
The PLUS feature allows you to (Grade 1 available upon request)
remove the cylinder from our pin > Approved by the Woodworkers Institute (formerly WIC)
tumbler box locks while the lock
remains in place. No mounting Note
screws need to be removed. Custom Master keying and General Master key systems available
Simply use a 2 mm (5/64") upon request.
hex wrench from the back to 2000 key changes are possible, special order 5 pin tumblers:
remove the cylinder for re-keying. - Please include a key plan
- Plan on 2–3 weeks to produce

→ C8173 Door Locks

> For right or left hand applications → Keyed Different
> 4 pin tumblers include 850 key changes
> Cylinder length 22 mm (7/8"), Bolt travel 19 mm (3/4")
> Surface mounted, requires a Ø24 mm (15/16") hole > Material: Brass-plated
> Key turns 360º
Finish National No. Item No.
19 31
(3/4")(1 15/64") brushed chrome C8173-KD-26D 232.14.400
12
(15/32") satin brass C8173-KD-4 232.14.500
4 3 Supplied With
(5/32") (1/4") Cylinder 2 Keys, Strike plate, Screws
length
23
22 (15/16") → Master Keyed, Keyed Different
(7/8")
40
34 (1 5/8") > Random key numbers only
(1 21/64")
> Please order master key separately (see below)
> Material: Lock and keys: Brass-plated
Finish National No. Item No.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
brushed chrome C8173-MKKD-26D 232.14.497
Supplied With
2 Keys, Strike plate, Screws
Note
Order master key and cylinder rosettes separately, below.

→ Cylinder Rosettes → Master Key

> For MKKD locks above
Ø22 8 > Material: Brass
(7/8") (5/16")

Mounting hole Ø29 Ø23 National No. Item No. 10
Ø24 (15/16") (1 9/64") (59/64") D4299 210.02.209
> Material: Brass → Keyed Alike
Locks

Finish National No. Item No. Finish Keying #’s National No. Item No.
brushed chrome C2017-26D 232.14.000 101 C8173-101-26D 232.14.401
satin brass C2017-4 232.14.001 103 C8173-103-26D 232.14.402
brushed chrome
107 C8173-107-26D 232.14.403
915 C8173-915-26D 232.14.404
107 C8173-101-4 232.14.503
satin brass
915 C8173-915-4 232.14.504
Supplied With
2 Keys, Strike plate, Screws

Keyed alike replacement keys page 10.39
