Locks and Catches
Cabinet Locks

SYMO 3000 Modular Removable Core Locking System

> For cylinder cores that are inserted from the front on-site
> Screw mounted

→ Sliding Door Lock

Installation > The rotary bolt further protects sliding doors
18 7
(11/16") 7.5 (9/32") against being pushed in
3 (5/16") 9.5 > The lock can only be locked and unlocked
(1/8") (3/8") with the key
25
50 32 38.5 (1 9/16") (1") 4 > Closure direction: 180º
> Material: Zinc Alloy; Finish: nickel-plated
(2") (1 1/4") (5/32")
Closure Direction A (right)
Ø18 Locking Item No.
(11/16") 7
(9/32") Closure direction A (right) 234.67.610
9.5 Closure direction B (left) 234.67.660
(3/8")

Closure Direction B (left)
→ PICCOLA-NOVA Espagnolette Locks

30
8 (5/16") (1 3/16") 11 > For divided profile rod 6 mm (1/4")
(7/16")
> Material: Zinc Alloy; Finish: nickel-plated
30
(1 3/16")
64 6 Handing Item No.
16 (2 1/2") (1/4")
(5/8") 75 Left 224.64.650
37.5 (2 15/16") Upper rod Right 224.64.600
(1 1/2") dimension
Note
Please consider the following measurements
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
15
6
(9/16") (1/4") when designing the cabinet and when choosing
4 (3/16") 14 14 (9/16") the accessories for the espagnolette lock:
Upper rod dimension: center of housing – 25 mm (1")
5 (3/16") (9/16") 14 (9/16") Lower rod dimension: center of housing – 25 mm (1")
22
(7/8")
Center of Internal
Ø18 housing height of
(11/16") cabinet
Lower rod
dimension
6
30 (1/4")
(1 3/16")
11
(7/16") 10
→ Angled Striking Plate
5
1.5 (3/16")
(1/8") 8 (5/16") Locks

40 18
(1 5/8") (11/16")
11 (7/16")
21
(13/16")

Lock cores pages 10.24–10.25 > For SYMO 3000 push and turn lock
Rod guides, locking bolt, > Material: Steel
top and bottom catch hooks page 10.35
Profile rod page 10.35 Finish Item No.
Accessories page 10.31 zinc-plated 239.01.910

www.hafele.com/us FC 10.33
