Locks and Catches
Cabinet Locks

National Locks High Security

Drawer Note > Approved by the Woodworkers Institute (formerly WIC)
Through the use of a shifter, the 360º
28 key travel turns the cam 90º in either Note
(1 1/8") direction. Actual application determines Custom Master keying and General Master key systems available
which cam position is the locked upon request.
position. Each lock is furnished with an 2000 key changes are possible, special order 5 pin tumblers:
3 RH LH alternate cam for opposite cam turn. - Please include a key plan
(1/8") Door Door - Plan on 2–3 weeks to produce
32 (1 1/4") 32 (1 1/4")

→ C8102 and C8103 Cam Locks

> For drawer, left, or right hand applications → Keyed Alike
> 4 pin tumblers include 850 key changes
> Cam turns 90º, key turns 360º
> Mounting Type: Flush
> Cylinder length: 27 mm (1 1/16")
C8102 > Maximum material thickness: (3/4")
shown > Material: Brass-plated

Finish Keying #’s National No. Item No.
brushed chrome 101 C8102-101-26D 235.10.401
brushed chrome 103 C8102-103-26D 235.10.402
brushed chrome 107 C8102-107-26D 235.10.403
brushed chrome 915 C8102-915-26D 235.10.404
satin brass 107 C8102-107-4 235.10.503
satin brass 915 C8102-915-4 235.10.504
Supplied With
2 Keys
Solid lines show locked 2 Cams
position of cam
Spur washer
Rosette

R/H Drawer > Mounting Type: Lipped/Overlay
> Cylinder length: 30 mm (1 3/16")
> Maximum material thickness: 22 mm (7/8")
Flush Lipped
10 overlay > Material: Brass-plated
(3/8")
L/H Drawer
Position of shifter Finish Keying #’s National No. Item No.
on back of lock brushed chrome 101 C8103-101-26D 235.10.301
brushed chrome 103 C8103-103-26D 235.10.302
brushed chrome 107 C8103-107-26D 235.10.303
16 brushed chrome 915 C8103-915-26D 235.10.304
(5/8") satin brass 107 C8103-107-4 235.10.603
19
19
10 (3/4") (3/4") satin brass 915 C8103-915-4 235.10.604
C8102 C8103 Supplied With
2 Keys
2 Cams Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Spur washer
Locks Rosette
→ Mounting Plate for Cam Locks

> Used where spur washer will not
embed into hard surfaces
> W x H: 56 x 32 mm (2 1/4"×1 1/4")
> Material: Steel

National No. Item No.
C2016-2C 210.02.081

Keyed alike replacement keys page 10.39
