Locks and Catches
Cabinet Locks

Timberline Modular Removable Core Locking System – Timberline

> Non-bore glass door locks
> Small high quality appearance
> Integrated knob to open door
> Fully cushioned to avoid glass damage
– Neoprene gasket on front surface
– Plastic tightening screw on back surface

→ Glass Door Lock

→ For Vertical Installation
Lock slips onto
edge of glass
31 door at any > For glass thickness: up to 8 mm (5/16")
(1 1/4") Fixed tab location –
provides no boring > Material: Outer body: Nylon; Color: black; Lever: Steel, nickel-plated
stop for required.
opposing
Fixed tab door. Finish Timberline No. Item No.
42
(1 11/16") nickel matt CB-367 233.18.630
13 nickel polished CB-361 233.18.730
(1/2")
11 13 → For Horizontal Installation
(7/16") (1/2")
29
Cam in locked position
(1 1/8") 8 > For glass thickness: up to 8 mm (5/16")
31
10 (5/16") (1 1/4") > Material: Outer body: Nylon; Color: black; Lever: Steel, nickel-plated
(3/8")
Set screw
tightens lock
to glass using Finish Timberline No. Item No.
Ø22 a flat-bladed 42
(7/8") screwdriver (1 11/16") nickel matt CB-357 233.18.600
nickel polished CB-351 233.18.700
13
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Cam in (1/2")
locked position
→ Glass Door Lock for Double Door → Push button Lock
Lock slips onto
edge of glass
31 door at any
(1 1/4") Fixed tab location –
provides no boring
stop for required.
opposing
Fixed tab door.
42 7
23
(1 11/16") (1/4") (15/16") 8
13 (5/16")
(1/2") Ø16.5 32 Ø19 48
(5/8") (1 1/4") (3/4") (1 7/8") 10
11 13
(7/16") (1/2") 2.5
(1/8")
Cam in locked position
Lock slips onto > Locks sliding doors
edge of glass door
at any location – > Compatible with all cores Locks
no boring required. > Small 19 mm (3/4") diameter for improved appearance
> Throw: 8 mm (5/16")
> Material: Lock case: Nylon; Cylinder housing: Zinc die-cast
> For glass thickness: up to 8 mm (5/16")
> Material: Outer body: Nylon; Color: black; Lever: Steel, nickel-plated
Color Timberline No. Item No.
black CB-175 234.65.000
Finish Timberline No. Item No.
nickel matt CB-377 233.18.660
nickel polished CB-371 233.18.760

Lock cores page 10.5
Angle strike & strike plate page 10.20
