Locks and Catches
Cabinet Locks

Timberline Modular Removable Core Locking System

16 15.5 3 > Separates the lock core from cylinder housing
(5/8") (5/8") (1/8")
> Any combination of locking systems can be obtained
> Manufacturer can install fully functional locking systems
> Simplifies the planning and changing of locking systems
> Lock cores can be replaced with the aid of the removal key

Square spindle Note
The cylinder housings and lock cores are
marked (see diagram above). A series of
furniture doors can all be locked with the
same direction of turn if the markings
Marking are positioned identically.
→ Cylinder Rosette

17.4 > For any cylinder body
(11/16")
7.6 > Material: Steel
(5/16") 2
24 (1/16")
(15/16")
Finish Timberline No. Item No.
nickel polished BZ-100 210.04.062
nickel matt BZ-700 210.04.070
brass polished BZ-500 210.04.054
bronzed BZ-400 210.04.017
black BZ-300 210.04.035
white BZ-800 210.04.071
Note
Requires Ø19 mm (3/4") hole for installation with lock cylinder.
→ Protective Cap → Removal Key

> Keeps interior of cylinder housing free of paint and dirt
after lock is installed > To remove lock cores
> Material: PVC > Material: Brass

Color Timberline No. Item No. Timberline No. Item No.
orange CC-100 210.02.095 KY-500-TA 210.02.004

→ Master Key → Replacement Key
