Locks and Catches
Cabinet Locks

Timberline Modular Removable Core Locking System

16 15.5 3 > Separates the lock core from cylinder housing
(5/8") (5/8") (1/8")
> Any combination of locking systems can be obtained
> Manufacturer can install fully functional locking systems
> Simplifies the planning and changing of locking systems
> Lock cores can be replaced with the aid of the removal key

Square spindle Note
The cylinder housings and lock cores are
marked (see diagram above). A series of
furniture doors can all be locked with the
same direction of turn if the markings
Marking are positioned identically.
→ Snap-In Lock Core

> For any cylinder body
> 5 plate levers = 900 possible key changes
> Material: Zinc die-cast, unfinished; Plate levers: Brass; Keys: Brass; Finish: nickel-plated
Keyed Different
Insert, push Lock face nickel nickel brass bronzed black white
until they polished matt polished epoxy epoxy epoxy
snap together
Item No. 210.04.606 210.04.710 210.04.803 210.04.106 210.04.302 210.04.500
Timberline No. LP-100 LP-700 LP-500 LP-400 LP-300 LP-820
Keyed Alike
nickel nickel brass bronzed black white
Lock face polished matt polished epoxy epoxy epoxy
Keying #’s Item No.
100 TA 210.04.615 210.04.720 210.04.812 210.04.115 210.04.311 210.04.510
101 TA 210.04.624 210.04.721 210.04.821 210.04.124 210.04.320 210.04.511
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
102 TA 210.04.633 210.04.722 210.04.830 210.04.133 210.04.339 210.04.512
103 TA 210.04.642 210.04.723 210.04.849 210.04.142 210.04.348 210.04.513
104 TA 210.04.651 210.04.724 210.04.858 210.04.151 210.04.357 210.04.514
105 TA 210.04.660 210.04.725 210.04.867 210.04.160 210.04.366 210.04.515
106 TA 210.04.679 210.04.726 210.04.876 210.04.179 210.04.375 210.04.516
107 TA 210.04.688 210.04.727 210.04.885 210.04.188 210.04.384 210.04.517
108 TA 210.04.697 210.04.728 210.04.894 210.04.197 210.04.393 210.04.518
109 TA 210.04.704 210.04.729 210.04.901 210.04.204 210.04.400 210.04.519
Supplied With
2 Keys

10

Locks

Keys page 10.6
