Locks and Catches
Cabinet Locks

Timberline Modular Removable Core Locking System

Typical > Permits locking from the front either in a fixed position in a lock
applications Locks strip or in a drawer front, in which case it travels with the drawer
> Can be installed on the left or right side of the cabinet as preferred
Lock
L 40.5
Side panel 4 (1 5/8")
(3/16")
AA1
A1
17.5
Desk with lock Modular pedestal with lock (11/16") Ø16.5
Mounted in fixed rail (1" min.) Mounted in drawer front Lock (5/8")
strip
1" min.
Drilling &
L routing diagram 40.5
Side panel 4 (1 5/8") J
(3/16")
AA1
A1
17.5
(11/16") Ø16.5 Q Drawer
Lock (5/8") wedge
strip
1" min.
J
→ A1 Lock Body with Lifting Pin

Q Drawer > Rotation: 180º
wedge > Lift: 12 mm (1/2")
Flat Head 2 > Material: Zinc die-cast, unfinished
#6 Ø6.4 (1/16") 18
(1/4") 40.5 (11/16")
(1 5/8")
Timberline No. Item No.
Ø16.5 (5/8") CB-100 234.85.001
12
32 (1/2") 35
(1 1/4") (1 3/8")
42
(1 5/8")
→ AA1 Lockbar Clip
32
1.2 (1 1/4") > To fit lock body A1
(1/16") > Mounts at any location along lockbar L
7 (1/4") > Material: Steel
28.5
(1 1/8")
10 Finish Timberline No. Item No.
zinc-plated LC-100 234.87.998 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Locks

Lock cores page 10.5
L Lockbar page 10.18
J Arresting pins page 10.18
Q Drawer wedges page 10.18
Insertion tool page 10.18
Miscellaneous strikes page 10.20
Flat head screws pages 12.7–12.8, 12.10, 12.13
