Hinges and Stays
Concealed Hinges

Salice

→ Release Device → Magnetic Device

40 Ø11.5
(1 9/16") (7/16")
Ø10
(3/8")
0.5

> Material: Plastic > For heavy doors
> Magnetic device to be used to increase the magnetic holding
strength
Color Model Item No. > It must always be used together with the DPM (356.06.462)
beige DPMSNB 356.06.462 > The suggested position of the DPM is the point of pressure
Note on the door
Order catch below. > The DPA can be positioned at any point along the opening edge
of the door
> Material: Plastic
→ Retaining Catch with Pin
40 Ø11.5 Color Model Item No.
(1 9/16") (7/16") beige DPASNB 356.06.472
Ø10
(3/8")
→ Magnetic PUSH Device Adapter
0.5
> Nail-on 26 Min.
> Installation: (1")
1) Apply the retaining catch to the magnetic release device
2) Close the door
3) The point of the retaining catch will show where to insert it
4) Reopen the door and press the retaining catch
> Material: Steel 8
(5/16")
Finish Model Item No. 32 10 Min.
nickel-plated DP28SN9 356.06.464 (1 1/4") (3/8")
> Surface mount with wood screws
→ Adjustable Magnetic Catch > Adjustable
9 1.2 > With assembly stop tabs
> Material: Plastic
(1/16") 16.6
(5/8")
9.3 0.7 Ø15 Color Model Item No.
(3/8")
Hinges and Stays > Inserts into the door (9/16") → Retaining Catch with Adhesive Strip Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
356.06.420
beige
DP84SNBR
> Increases holding power
> Ideal for large heavy doors
> Features depth adjustment
> Ø x D: 15 x 11 mm (9/16" x 7/16")
> Material: Housing: Plastic; Plate: Steel

Finish Model Item No.
gray DP39XXG 356.06.466 > Adhesive backed
> Material: Steel

Finish Model Item No.
nickel-plated DP38XX91 356.06.465

FC 9.32 www.hafele.com/us
