Drawer Slides
Concealed Undermount

Salice Full Extension

> Dynamic weight capacity: 35 kg (75 lbs.)/pair
> Unique lengths for 300, 350, 400, 450 mm (12", 14", 16", 20")
deep panels
> Cushioned open
> For drawer boxes 13–16 mm (1/2"–5/8")
> Choose from soft close or push-to-open
> Interior drawer box width: ICW-41
> Material: Steel; Finish: zinc-plated

→ A6555 Closet Slide with Soft Close → A6557 Closet Slide Push

Length Item No. Length Item No.
280 (11") 421.23.228 280 (11") 421.23.428
320 (12 5/8") 421.23.232 320 (12 5/8") 421.23.432
380 (14 15/16") 421.23.238 380 (14 15/16") 421.23.438
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
480 (18 7/8") 421.23.248 480 (18 7/8") 421.23.448 8
Supplied With 20 pcs. each L/R, packed separately Supplied With 6 pair
Note Front locking clips are required Note Front locking clips are required
Drawer Slides
SP LC

FRONT 9 14 9 9 14 9

12
29 41
a
37 + SP* b
Panel *Setback to front edge of CM
depth LC a b is thickness of drawer box → Clips, required
12" 280 128 160 FRONT material. If using 5/8"
material to 4th hole back
14" 320 128 160
37 + 16 = 53 > Material: Plastic
16" 380 128 160
20" 480 224 256
mm mm mm Color/Version Item No.
gray/height adjustable 421.23.000
LC = Length of drawer not including box FRONT orange/6 way adjustable 421.23.001
SP = Thickness of box FRONT material Supplied With
Note that total length of drawer box is LC + SP.
Right/left clips

www.hafele.com/us FC 8.59
