Drawer Slides
Concealed Undermount

Salice Full Extension

→ A7555 Futura 16
Inside cabinet width
ICW

Min. 5
ICW - 41 (3/16")
Max. 16
(5/8")
9.5
(3/8")
12 (1/2")
13 (1/2")
31.5 41
29
(1 1/4") (1 1/8") (1 5/8")
Flat Head
#6 20 21
(13/16") (13/16")
Frameless Min. 320 (12 5/8") Calculation formula for outside drawer width
313 (12 5/16")
Drawer Side Thickness: Minimum: 12 mm (1/2")
305 (12") Cabinet Maximum: 16 mm (5/8")
381 (15") Maximum Drawer Height = Opening minus 25 mm (1")
32 32
(1 1/4") 256 (1 1/4") Drawer side 16 15 14 13 12
(10 1/16") thickness (5/8") (19/32") (9/16") (1/2") (15/32")
Min. 397 (15 5/8") Deduct from 9 11 13 16 17
390 (15 3/8")
381 (15") Cabinet ICW (3/8") (7/16") (1/2") (5/8") (21/32")
457 (18")
32 32
(1 1/4") 320 (1 1/4")
(12 5/8")
Min. 473 (18 5/8") Drawer box
466 (18 3/8") 33 length
Cabinet
457 (18") 533 (21") (1 5/16")
8 32 11 ICW - 41
416 (1 1/4") (7/16") (1 5/8")
(16 3/8")
Ø6 x 10
Min. 549 (21 5/8") (1/4 x 3/8")
542 (24") 610 (24") (1/4") 10 - 15
7
Drawer Slides Mounting (1 7/16") 33 (1 5/16") (18 7/8") (1 1/4") → Clips, required (3/8 - 9/16")
Cabinet
533 (21")
32
Setback
32
(1 1/4")
4
480
37
position
> Dynamic weight capacity: 35 kg (75 lbs.)/pair
> Integrated soft close with 52 mm (2 1/16") closing range
> Meets or exceeds BHMA grade 1 testing requirements > Material: Plastic
> Slotted hole for depth adjustment
> Front clips disconnect for easy drawer insertion and removal Color/Version Item No.
> Material: Steel; Finish: zinc-plated gray/height adjustable 421.23.000
orange/6 way adjustable 421.23.001 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Slide length Drawer box length Item No. Supplied With
Right/left clips
266 (10 1/2") 229 (9") 433.17.723
313 (12 5/16") 305 (12") 433.17.730
390 (15 3/8") 381 (15") 433.17.738 → Rear Face Frame Mounting Brackets, optional
466 (18 3/8") 457 (18") 433.17.745
542 (21 3/8") 533 (21") 433.17.753 > Material: Steel; Finish: zinc-plated
Note Version Item No.
Face frame add rear bracket with minimum cabinet depth 6–45 mm Standard 433.17.000
(1/4"–1 3/4")
Narrow 433.17.001
Note 2 pcs. required (for 1 pair of slides).

Flat head screws pages 12.7-12.8, 12.10, 12.13
