Drawer Slides
Double-Wall Drawer System

Grass Vionaro

> A complete drawer system for modern cabinetry
> 90° straight corners and sides
> Slim 13 mm (1/2") side width
> Maximum drawer width: 1219 mm (48")
> Integrated height and side adjustment, tilt adjustment at back
> For face frame and frameless cabinets
> Optional 4D depth adjustment
> For use only with Dynapro 2D concealed undermount slides

→ Vionaro H89 → Dynapro, required

C D

VARIANTA Pan Head
3 #8

> Side height: 89 mm (3 1/2") > Material: Steel; Finish: zinc-plated
> Material: Steel
Drawer length Item No.
Drawer length silver gray graphite white 381 (15") 433.19.440
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
381 (15") 550.41.539 550.41.339 550.41.739 457 (18") 433.19.447 8
457 (18") 550.41.546 550.41.346 550.41.746 533 (21") 433.19.455
533 (21") 550.41.554 550.41.354 550.41.753

ICW
RWB = ICW - 42 (1 21/32")
min. RWB = 120 mm (4 23/32")
RWB = ICW - 42 (1 21/32") Drawer Slides
(2 5/16”) 59 RWH
Back panel

BL = Drawer Length - 13 (1/2") min. 75 (2 15/16”) 89 (3 1/2") 75 (2 15/16") 32 (1 1/4")

Bottom panel 8.5 (11/32") 31 (1 7/32")

min. 37 (1 15/32”) 16 (5/8")

BB = ICW - 21 (13/16") 28.5 (1 1/8") 16 (5/8")

BB = ICW - 21 (13/16") 14.5
(9/16")
Accessories page 8.31
Pan head screws pages 12.9-12.10
Varianta screws page 12.16

www.hafele.com/us FC 8.27
