Drawer Slides
Double-Wall Drawer System

Grass Vionaro

→ Vionaro H185 → Dynapro, required

C D

VARIANTA Pan Head
3 #8
> Side height: 185 mm (7 1/4") > Material: Steel; Finish: zinc-plated
> Material: Steel
Drawer length Item No.
Drawer length silver gray graphite white
381 (15") 550.43.539 550.43.339 550.43.739 381 (15") 433.19.440
457 (18") 550.43.546 550.43.346 550.43.746 457 (18") 433.19.447
533 (21") 550.43.554 550.43.354 550.43.753 533 (21") 433.19.455
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Note Vionaro only works with Dynapro 16 2-D. 8
ICW
RWB = ICW - 42 (1 21/32")
min. RWB = 120 mm (4 23/32")
RWB = ICW - 42 (1 21/32")
RWB = ICW - 42 (1 21/32") 10 (13/32")
10 (13/32") Back panel 155 (6 1/8") RWH
(6 1/8") 155 RWH
Back panel Drawer Slides

96
169
(2 1/2") 155 (6 1/8") 64 (2 1/2") 155 (6 1/8") (6 2/32") 185 171 (3 25/32")
64 Bottom panel (7 9/32") (6 23/32")
Bottom panel BL = Drawer Length - 13 (1/2") BL = Drawer Length - 13 (1/2")
32
63 (2 1/2") 63 (2 1/2") 8.5 (1 1/4")
31
BB = ICW - 21 (13/16")
16 (5/8")
Bottom BB = ICW - 21 (13/16") Bottom (11/32") 16 (1 7/32")
16 (5/8") (5/8")
min. 37
(1 15/32”)
BB = bottom panel width ICW = inside cabinet width
BL = bottom panel length RWB = back panel width 16 (5/8")
IDW = inside drawer width RWH = back panel height 28.5
(1 1/8")
BB = ICW - 21 (13/16") 14.5
(9/16")
Accessories page 8.31
Pan head screws pages 12.9-12.10
Varianta screws page 12.16
