Sliding and Roller Shutter Systems
Folding Cabinet Door Fittings

Häfele Slido F-Fold 61 25A/50A

> Door thickness: 16–19 mm (5/8"–3/4")
> Door weight: up to 25 kg or 50 kg (55 or 110 lbs.) per pair of doors
> For front hung folding cabinet doors
> For 2 panels that can be folded to either the left or right side
of the cabinet
> For 4 panels where 2 doors fold left and 2 doors fold to the right
of the cabinet
> Outer panels will use standard concealed hinges
> Panels are equal in size

Calculation of door width

2 (3/32") 2 (3/32") 2 (3/32") 2 (3/32")
7 2 pairs of doors 1 pair of doors

B = IA + 2G – 6(1/4")/4 B = IA + 2G – 2 (3/32")/2
Sliding and Roller Shutter Systems
B = door width
Installation dimensions G = door overlap on cabinet side panel
56 IA = internal cabinet width
(2 7/32") Space requirement T = cabinet top and bottom panel thickness
(1 5/32") 60+T (2 3/8") Drilling pattern for door
29

Ø35x11.5
T 56+T (2 7/32"+T) (Ø1 3/8" x 7/16") 2 (3/32")
(2 7/32") 56+T (2 7/32")
56 24 (15/16")
Ø35 (1 3/8") 64 (2 17/32")

64 (2 17/32") 32 (1 1/4")

Ø35 (1 3/8") 22.5 21.5 13
(7/8") (27/32") (1/2") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

25 kg 50 kg
48 (1 7/8")
Ø35x12
(Ø1 3/8" x 15/32")
22.5
(7/8")
28.5
(1 1/8")
pattern for adjustable
center hinge
T A with standard center hinge or
B with adjustable center hinge
