Sliding and Roller Shutter Systems
Sliding Glass Door Fittings

→ HAWA Clipo 36 GPK/GPPK IF Set

Version Supplied With Item No.
2 running gears
1 clear threshold floor guide
Clipo 36 GPK 405.02.410
2 door stoppers with clip-in door stopper
Mounting material
For 1 door 2 running gears
1 bottom guide
Clipo 36 GPPK 3 covers 405.02.411
2 door stoppers with clip-in door stopper
Mounting material
Supplied With
1 set
Order Reference
Please order running and guide tracks and glass fixing profiles (GPK: top, GPPK: top and bottom) separately. Soft closing mechanism on one side
is possible from pitch length of min. 260 mm (10 1/4"), both sides from 460 mm (18 1/8"). Please order soft closing mechanism set separately.

→ Tracks and Accessories

Description Material Finish Length/Door weight Item No.
12
(1/2") 2.5 m (8' 2 7/16") 405.03.202
Glass fixing profile, for top and
24 bottom of door, for glue mounting Aluminum anodized, silver
(1")
3.5 m (11' 5 13/16") 405.03.203
7
2.5 m (8' 2 7/16") 405.00.622
Upper track, pre-drilled,
for screw mounting Aluminum anodized, silver
3.5 m (11' 5 13/16") 405.00.623
2.5 m (8' 2 7/16") 405.02.622
Double upper track, pre-drilled,
for screw mounting Aluminum anodized, silver
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
3.5 m (11' 5 13/16") 405.02.623
Soft closing mechanism, optional up to 15 kg (33 lbs.) 405.10.073
for screw mounting to housing.
One set includes two mechanisms. Plastic gray 15–27 kg (34–57 lbs.) 405.10.074
Two sets are required for dual
soft closing of two doors. 26–36 kg (57–79 lbs.) 940.48.045
Service port for upper track Sliding and Roller Shutter Systems
(to access running gear Plastic gray – 405.00.072
after installation)
Service port for double upper track
(to access running gear Plastic gray – 405.00.074
after installation)
