Sliding and Roller Shutter Systems
Sliding Glass Door Fittings

HAWA Clipo 16 GPK/GPPK IF

> Door weight: max. 16 kg. (35 lbs.)
GPK Version > Door height: max. 1,400 mm (55 1/8")
> Door width: max. 1,000 mm (39 3/8")
> For glass thickness: 6–6.35 mm (1/4")
> Height adjustment: +2 / -1 mm (+ 3/32" / -1/32")
> No glass drilling
> Clip-on running gear provides quick installation
> For bypassing, frameless glass doors
> Top hung system allows for no track or groove to be placed
in the bottom of the cabinet
> GPK Version: Glass fixing profile is not required on the bottom
of the door
> GPPK Version: Glass fixing profile is on the top and bottom
> Optional soft closing mechanism

Installation dimensions
Clipo 16 GPK
30
(1 3/16") 2 30 10
(3/32") (1 3/16") (13/32")
19 19 14
(3/4") (3/4") (9/16")
Running gear installation 16 (5/8") 20 5 (3/16")
2
20
7 Running gear (25/32") (3/32") (25/32")
installation
+2 (3/32")
-1 (1/32") +2 (3/32")
-1 (1/32")
Sliding and Roller Shutter Systems
A A-22
GPPKGPPK 12 (7/8") A - 9 (11/32")
(15/32") 12 2
2 (3/32") A-36 A (15/32") (1/16") A - 23 (29/32")
GPKGPK (1 7/16")
6 (1/4") 8 (5/16") 6 (1/4") (1/4") 8 (5/16") (1/4")
6
6
Clipo 16 GPPK
30 30 10
GPPK (1 3/16") 2 (1 3/16") (13/32")
(3/32")
19 19
(3/4") GPK (3/4") 14 (9/16")
16 (5/8") 20 5 19 19 4
4
20 2 (25/32") (3/16") (3/4") (5/32") (3/4") (5/32")
(25/32") (3/32") 14 10 14 17.5
(9/16") (13/32") (9/16") (11/16")
+2 (3/32")
+2 (3/32") -1 (1/32") Soft close mounting
-1 (1/32") Door with one soft closing mechanism.
A A-22 A A-9 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
