Sliding and Roller Shutter Systems
Sliding Wood Door Fittings

HAWA Combino 65 H MF

> Door weight: max. 65 kg (143 lbs.)
> Door height: max. 2,600 mm (102 3/8")
> Door width: max. 1,400 mm (55 1/8")
> Door thickness: 25 mm (31/32”)
> Height adjustment: +4 / -2 mm (+5/32” / -3/32”)
> Optional soft closing mechanism

Installation dimensions
66 15 (19/32") 16 (5/8")
36 (2 19/32") 45
(1 13/32") (1 25/32")
25 36
(31/32") (1 13/32")
18 87 (3 7/16")
(23/32") 54 (2 1/8")

7 (9/32") +4 (5/32")
-2 (3/32")
7 KH

(1 1/2")
25 (31/32") 11 (7/16") 25 (31/32") 23 (29/32") C = KH - 38
Sliding and Roller Shutter Systems
88 (3 15/32") 11 (7/16")
55
24 (2 5/32")
(15/16")
Drilling pattern 25
(31/32")
36
(1 13/32") 40 41 (1 5/8")
57 (1 9/16")
(2 1/4") ≥80 (3 5/32")
45 10
(1 25/32") (13/32")
16
(5/8") Ø25x10
(31/32"x13/32")
60 With soft and self closing
(2 3/8") Ø3x3 C = door height
(1/8") KH = cabinet height
Door overlap
75 IA Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(2 15/16") B
20
Ø3x3 (25/32")
(1/8")
28 2 (3/32") 2 (3/32")
(1 3/32") B
19 (3/4") 94 Door width B = (IA + 16)/2
(3 11/16")
IA
B 20 20 B
94 (25/32") (25/32")
(3 11/16")

2 (3/32") 2 (3/32")
B
Door width B = (IA + 36)/3
IA internal cabinet width, B door width
