Sliding and Roller Shutter Systems
Sliding Wood Door Fittings

HAWA Regal A 25 H VF

> Door weight: max. 25 kg (55 lbs.)
> Door height: max. 2,400 mm (94 1/2")
> Door width: max. 1,200 mm (47 1/4")
> Door thickness: 19–26 mm (3/4"–1 1/32")
> Eccentric height adjustment: ±2 mm (3/32") on running gear
> Rails are not visible from the front of the cabinet
> Easy door mounting

Installation dimensions
≥35 17
(1 3/8") (11/16") 10
(13/32")

28
25 7.5 (1 3/32")
(31/32") (9/32") 40
(1 9/16")

7

Sliding and Roller Shutter Systems

Drilling pattern

8 19
(5/16") (3/4")
63
(2 15/32")
Ø5 x 14
(3/16") (9/16") 25
(31/32") 14 (9/16") (13/16")
Ø20 x 10 32 21
(25/32") (13/32") (1 1/4")

6 (1/4")
41
≥20 12 (1 5/8")
(25/32") (15/32")
60 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(2 3/8")

Ø5 x 14
(3/16") (9/16")
32
(1 1/4")

48
(1 7/8")
60
(2 3/8")

FC 7.48 www.hafele.com/us
