Casters, Feet, Legs, Table Fittings
Table Fittings

Leg Brackets

→ Table Fitting

→ Angle Fitting

> With side holes for screw mounting to apron
> Allows for sturdy corner connections for tables, frames, cabinets,
work benches, shelving, mobile tables, etc.
> Material: Steel
6
Finish Item No.
nickel-plated 641.01.711

125 27
(4 15/16") 32 32 (1 1/16")
14 32 14 (1 1/4") (1 1/4")
(9/16") (1 1/4") (9/16") 22 27
(7/8") 9 (1 1/16")
(3/8")
26 32 54 92
Ø5.2
26
(1 1/16") (1 1/4") (3/16") (1 1/16") (2 1/8") (3 5/8")
13 (1/2") 7 (1/4")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
12 3 (1/8") Pan Head Casters, Feet, Legs, Table Fittings
(1/2") 12 #10
(1/2")

→ Corner Brace → Anti-Sag Bars

Ø10
(3/8")
Pan Head 1549 (61")
#10 A
40
(1 9/16") A
A-A (1:1)
51 (2") 2
38 (1 1/2") (1/16")
74 74 Ø6 (1/4") 40˚ 19 (3/4")
(2 15/16") (2 15/16")
30
(1 3/16") > To be used under table tops to keep from sagging
2
6 (1/16") Ø5 > Color: black
(1/4") (3/16")
Length Item No.
> Simple/economical attachment of table legs to frame
> The ends of the brace are set into grooves in frame 1549 (61") 630.46.382
> The table leg is secured using the center hole 1245 (49") 630.46.384
> Material: Steel, galvanized 787 (31") 630.46.383
Supplied With
Item No. Wood screws
641.00.901
Note Tables designed using corner braces can be stored, packed and
transported in RTA form.

Pan head screws pages 12.9-12.10

www.hafele.com/us FC 6.87
