Casters, Feet, Legs, Table Fittings
Turntables

Turntables

> Economical turntables for small offices, entertainment centers,
kitchens, etc.

→ Turntable → Turntable

170 (6 11/16")
Turntable
Ø130 (5 1/8")

258 (10 3/16")
6 27 (1 1/16")
13 Ø72 (2 3/4")
(1/2")
2 Ø16
(1/16") Hole spacing (5/8")
230 (9 1/16") Ø185 - Ø205 (7 5/16" - 8 1/16")
Casters, Feet, Legs, Table Fittings
> Rotates 360°
> Weight capacity: 120 kg (260 lbs.) > Ball bearing mounted
> Material: Steel, unfinished > Weight capacity: 100 kg (220 lbs.)
> Material: Steel, unfinished
Item No.
646.29.902 Item No.
646.15.014
→ Turntable
→ Turntable, spring loaded

155 (6 1/8")
Turntable 170 (6 11/16")
Ø118 (4 5/8") Turntable
Ø130 (5 1/8")

10.5 (7/16") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
27 (1 1/16")
Hole pitch Ø16
Ø64 (2 1/2") (5/8")
Hole pitch
Ø180 (7 1/16") Hole spacing Ø16
Ø185 - Ø205 (7 5/16" - 8 1/16") (5/8")
> Weight capacity: 150 kg (330 lbs.)
> Material: Steel, galvanized > Rotates 90° to the right and left sides
> Ball bearing mounted
> After turning, a steel spring returns the turntable to its
Item No. original position
646.18.908 > Weight capacity: 100 kg (220 lbs.)
> Material: Steel, unfinished

Item No.
646.15.023
FC 6.90 www.hafele.com/us
