Casters, Feet, Legs, Table Fittings
Levelers

Levelers

> Slightly oversized to allow for material thickness tolerances
> Holes on one side for fastening

→ U-Bracket

> Material: Steel, epoxy-coated; Finish: black

Pan Head
#8 6
3.5 Ø13 3.5 (5/32") 8 Ø13 8 (5/16") 29
20
(5/32") (1/2") (13/16") 6.5 Ø13 6.5 (1/4") 26 (5/16") (1/2") (1 1/8")
32 (1/4") (1/2") (1 1/16") 32
(1 1/4") 32 (1 1/4")
(1 1/4")
11 50 50 11 50
11
(7/16") (2") (7/16") (2") (7/16") (2")
1.6
Ø17 8 23 1.6 Ø17 8 1.6 Ø17 8 32 (1/16")
29
(11/16") (5/16") (15/16") (1/16") (11/16") (5/16") (1 1/8") (1/16") (11/16") (5/16") (1 1/4")
Thread Size 19 mm (3/4") thick material 25 mm (1") thick material 28 mm (1 1/8") thick material
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
1/4"-20 637.95.311 637.95.321 - Casters, Feet, Legs, Table Fittings
5/16"-18 637.95.312 - -
M10-1.5 mm 637.95.314 637.95.324 637.95.334

→ U-Bracket with M10 Threads → Threaded Plate

X
Ø13 32 12
(1/2") (1 1/4") (1/2")
11
Ø22 (7/8")
8
3
Ø17 (1/8")
> Material: Steel, epoxy-coated; Finish: black
32 47.5
(1 1/4") (1 7/8")
Thickness X Item No.
19 (3/4") 20 (13/16") 637.95.314
Ø5
26 (1") 26 (1") 637.95.324 3/16" 32 (1 1/4")
29 (1 1/8") 29 (1 1/8") 637.95.334
> Screw mounted
> With M10-1.5 mm (1/16") internal thread
> Heavy-duty; for levelers or casters
> Material: Zinc, plated; Internal thread element: Steel

Finish Item No.
nickel-plated 637.07.910
Supplied With
50 pcs.

Pan head screws pages 12.9-12.10
