Casters, Feet, Legs, Table Fittings
Table Legs

Component System - Accessories

or or
For this range
of casters see
page 6.39

Washer is required for all other casters with M10
threaded stems. Note: Caster selected must have
a threaded stem at least 22 mm (7/8") long.
→ Height Adjuster → Leveler

6
47
(1 7/8") 16
(5/8")
25
(1")
Ø62
(2 1/2")
> Ø: 60 mm (2 3/8")
> Press-fit into bottom of Ø60 mm tube > Press-fit; offers + 26 mm (1") of adjustment
> Offers 111 mm (2 3/8") of adjustment > Compressed height: 16 mm (5/8"), when completely screwed down
> Compressed height: 35 mm (1 3/8"), when completely screwed > Material: Plastic
down
> Fully extended height: 146 mm (5 3/4")
> Material: Plastic Color Item No.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
black 635.06.009 Casters, Feet, Legs, Table Fittings
Color Item No. Supplied With
black 654.35.310 4 Levelers
Supplied With
Sleeve → Washer
→ M10 Thread Insert Ø60 Ø10
(2 3/8") (3/8")
M10 - 1.5 M

50
(2")
Ø57 2 (1/16")
(2 1/4")
> For mounting plate and caster attachment > Ø: 60 mm (2 3/8")
> Presses into top or bottom of tube > For bottom of legs when used with casters
> Material: Steel/Plastic; Color: black > M10 male threads required
> Material: Steel

Item No. Finish Item No.
635.06.026 black 635.16.399
Note
Caster selected must have a threaded stem at least 22 mm (7/8”) long.
Washer is required.

Casters page 6.39
Varianta screws page 12.16
Flat head screws pages 12.7-12.8, 12.10, 12.13
