Casters, Feet, Legs, Table Fittings
Base Cabinet Feet

Levelers

> Offers a wider range of adjustment with fewer items
> Allows for greater flexibility at installation
> Components ordered separately

→ Adjustment Foot → Mounting Socket

32 10
(1 1/4") (3/8")
Adjustment 11
+28 55 (1/2")
(1 1/8") (2 1/8")
32 25
(1 1/4") (1")
55
6 Min. 91/141 (2 1/8")
(3 9/16"/5 9/16")
> Dowel mounted
> Material: Plastic
Casters, Feet, Legs, Table Fittings
Color Item No.
> Shaft Ø: 30 mm (1 3/16") black 637.54.330
> Weight capacity: 113 kg (250 lbs.)
> Material: Plastic; Color: black → Mounting Socket

32
Base height Item No. (1 1/4")
91–119 (3 9/16"–4 11/16") 637.54.311
141–169 (5 9/16"–6 11/16") 637.54.313 32 20
(1 1/4") (3/4")
48
→ Extension Tube (1 7/8")
77
(3")
> Screw mounted
50 > Material: Plastic
(2")
78
(3 1/16") Color Item No.
black 637.54.335
→ Plinth Panel Clip
26
(1 1/16")
9 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(3/8")
> Material: Plastic 40 Ø29 38
(1 5/8") (1 1/8") (1 1/2")
31
(1 1/4") 11
Color Item No. 39 (1/2")
black 637.54.320 (1 1/2")

> Screw mounted to base panel
> Material: Plastic

Color Item No.
black 637.54.340

FC 6.34 www.hafele.com/us
